INTRODUCTION
This vacuum dryer is mainly used in the drying of easily decomposed, polymerized and heat-sensitive materials under high temperature. It is widely used in pharmaceutical, chemical, food, electronics and other industries.
FEATURE
The boiling point of the material can be lowered in a vacuum state, which effectively increases the driving force of the evaporator and saves energy.
There are many options for heating medium, such as low-pressure steam and hot water.
If disinfection is carried out before drying, the equipment can ensure that no pollutants will be produced during the drying process and can meet GMP requirements
This series of products is a static dryer, so it will not destroy the original form of the material.
SIP
CIP
The flat-plate heater can make the heating area and temperature of the material more uniform and stable.
TECHNICAL PARAMETER
Model | FZG-4 | FZG-8 | FZG-16 | FZG-20 | FZG-32 | FZG-36 | FZG-40 | FZG-48 | FZG-60 |
Inner dimension(mm) | 460x780x690 | 460x780x1180 | 660x980x1180 | 660x980x1430 | 1280x980x1180 | 1280x980x1310 | 1280x980x1430 | 1300x1380x1180 | 1300x1380x1430 |
Overall dimension(mm) | 720x1000x1400 | 720x1000x1630 | 890x1200x1630 | 890x1200x1880 | 1510x1200x1630 | 1510x1200x1770 | 1510x1200x1890 | 1530x1600x1630 | 1530x1600x1880 |
Layer | 4 | 8 | 8 | 10 | 8 | 9 | 10 | 8 | 10 |
Level space(mm) | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
Baking tray dimension(mm) | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 | 400x600x45 |
Tray | 4 | 8 | 16 | 20 | 32 | 36 | 40 | 48 | 60 |
Capacity(kg/batch) | 12 | 24 | 48 | 60 | 96 | 108 | 120 | 144 | 180 |
Plate dimension(mm) | 430x640x25 | 430x640x25 | 630x840x25 | 1250x840x25 | 1250x840x25 | 1250x840x25 | 1270x1240x25 | 1270x1240x25 | 1270x1240x25 |
Inner temperature | <100℃ | <100℃ | <100℃ | <100℃ | <100℃ | <100℃ | <100℃ | <100℃ | <100℃ |
Vacuum degree (Mpa) | >-0.098 | >-0.098 | >-0.098 | >-0.098 | >-0.098 | >-0.098 | >-0.098 | >-0.098 | >-0.098 |
Vacuum pump power (Kw) | 1.1 | 1.5 | 2.35 | 2.35 | 3.85 | 3.85 | 4 | 5.5 | 7.5 |
Weight(kg) | 1000 | 1400 | 1600 | 2000 | 2500 | 3000 | 3500 | 3800 | 4500 |
